2. WIRING
13
3) Fabricate the FRU-NMEA-PFF-060 cable as follows.
1) On the end of the side without the FRU connector, cut into the one end part of the FRU
connector. Expose inner vinyl sheath by approx. 40 mm. Be careful not to damage inner
shield and cores.
2) Wrap the drain wire with a vinyl tube.
Note: Make sure the rubber bush and ring are oriented correctly (as shown in the figure
above).
3) Twist the blue and white core wires and a resistor assembly, and attach a closed-end lug
to the wires.
40 mm
40 mm
40 mm
FRU-NM
EA-PFF-060
FRU-NM
EA-PFF-060
Resistor Assembly
(120 OHM-1007#24-L50 supplied)
Resistor Assembly
(120 OHM-1007#24-L50 supplied)
Rubber Bush (Large)
䚷
+ Ring
Rubber Bush (Large)
䚷
+ Ring
䠍䠌㻌䡉䡉䠍䠌㻌䡉䡉䠍䠌㻌䡉䡉
Rubber Bush (Large)
䚷
+ Ring
Rubber Bush (Large)
䚷
+ Ring
Vinyl tapeVinyl tape
CapCap
Twist and fix the
closed-end lug to the tip.
Twist and fix the
closed-end lug to the tip.
Resistor Assembly
(120 OHM-1007#24-L50 supplied)
Resistor Assembly
(120 OHM-1007#24-L50 supplied)
Rubber Bush (Large)
䚷䚷䚷
+ Ring
Rubber Bush (Large)
䚷䚷䚷
+ Ring
