1. OPERATION
1-6
1.5 User Menu Operation Overview
Most operations of your NAVpilot are done through the user menu. The instructions
below provide a quick introduction on how to select a menu and change menu set-
tings.
1. In the STBY, AUTO or NAV mode, press and hold the MENU/ESC key to open
the user menu.
Note: You can also open the user menu by the following methods.
• Press the MODE key to open the [Select Mode] window, then rotate the Course
control knob to select [Menu] and push the knob.
• Press the MENU/ESC key to open the [Parameter Menu] window, then rotate
the Course control knob to select [User Menu] and push the knob.
2. Rotate the Course control knob to select (highlight) a menu item, then push the
knob.
3. For the menu with “layers”, repeat step 2 as necessary. To go back one layer in a
menu, press the MENU/ESC key.
4. Rotate the Course control knob to select an option or setting, then push the knob.
5. Press and hold the MENU/ESC key to close the user menu.
Note: For the sake of brevity, the procedures outlined in this manual use the following
terminology/phrases when referring to menu operations.
• “Open/close the user menu.” This means “Open/close the user menu as outlined in
step 1 or step 5 of the above procedure.”
• “Select .” This means “Rotate the Course control knob to select and push
the knob” in similar manner as outlined in step 2 and step 3 of the above procedure.
7 Working indicator Spins clockwise if the system is working properly. If it is not
spinning the system is not working.
No. Name Description
Back button
Select menu items with arrows to
access the next menu layer.
Menu selection
is highlighted.
Operation guide
