Je bekijkt pagina 9 van 44
1
1. MOUNTING, WIRING
1.1 Preparation
Mounting type
You can install the monitor unit as follows. See the outline drawings at the back of this manual for
mounting dimensions.
• Flush mounting, fixed at rear (standard)
• Flush mounting, fixed at front (option)
• Desktop mounting (option)
• Flush mounting, fixed at rear, with hood (option)
• Desktop mounting, with hood (option)
Note 1: The face of the LCD monitor is made of glass. Handle it with care.
Note 2: For flush mounting, the mounting surface must be flat. Do not install the unit on an uneven
surface. Also, take care that the monitor unit does not fall during the installation.
Mounting location
When you select a mounting location, remember the following points:
• Make sure the mounting location is strong enough to support the weight of the unit. See the out-
line drawings at the back of this manual.
• Locate the unit away from direct sunlight. An LCD may black out or condensation may occur if
the LCD is exposed to direct sunlight for a long time.
• Select a location where the display can be easily viewed and the controls can be easily operat-
ed.
• Leave enough space around the unit for service and maintenance. See the outline drawings at
the back of this manual for minimum service clearance.
• Locate the unit away from areas subject to water splash and rain. This monitor unit is for indoor.
• Observe the compass safe distances (see page iii) to prevent interference to a magnetic com-
pass.
Note: If the unit is installed with the screen tilted downwards, the appropriate glass fixing kit (see
“Optional supply” on page vii) must be used.
Included items
• Monitor Unit • Cable Assembly (1 pc.)
• Flush Mount Fixture 15 (2 pcs.) • Hard Cover 15 (1 pc.)
• Flush Mounting Sponge H15 (2 pcs.) • Glass Tube Fuse (3 pcs.)
• Flush Mounting Sponge V15 (2 pcs.) • Operator’s Manual (1 pc.)
• Washer Head Screw (6 pcs.) • Material Data Sheet (C-RoHS, 1 pc.)
• Cable Tie (4 pcs.)
