2. PLOTTER DISPLAY OVERVIEW, TRACK
2-7
2.3 About Tracks
The GP-170 stores 1,000 points of track.
2.3.1 How to start or stop plotting and recording of the track
Press the PLOT ON/OFF key to start or stop plotting and recording of the track. The
pop-up message "Resuming Track Plot" or "Stopping Track Plot" appears at the left
side of the display for two seconds. When track plotting is stopped, the icon ap-
pears at the bottom left corner of the display.
2.3.2 How to set the track plotting interval
In drawing the track, the position of your ship is stored into the memory of this equip-
ment at an interval of time or distance. A shorter interval provides better reconstruction
of the track, but the storage time of the track is reduced. When the track memory be-
comes full, the oldest track is erased to make room for the latest.
1. Press the MENU/ESC key to open the main menu.
2. Select [2 Track/Mark] then [1 Track REC].
3. Select [1 Time] or [2 Distance].
[Time]: Enter the time interval with the numeric keys (setting range: 0001 (1 sec)
to 6000 (60 min)).
[Distance]: Enter the distance interval with the numeric keys (setting range: 00.01
to 99.99 NM).
4. Move the cursor to [Enter] then press the NU/CU ENT key.
5. Press the MENU/ESC key to close the main menu.
Time Distance
