2. PLOTTER DISPLAY OVERVIEW, TRACK
2-5
2.1.12 How to display the time mark
You can display the time mark on the track every hour on the hour.
1. Press the MENU/ESC key to open the main menu.
2. Select [1 Display] then [4 Time Mark].
3. Select the color for the time mark. To turn the time mark off, select [8 Off].
4. Press the MENU/ESC key to close the main menu.
2.1.13 How to display the names for marks and waypoints
You can display the names for marks and waypoints.
1. Press the MENU/ESC key to open the main menu.
2. Select [1 Display] then [5 Mark/WPT Name].
3. Select [1 On (All)], [2 On (WPT)] or [3 Off].
[On (All)]: Displays the names for marks and waypoints.
[On (WPT)]: Displays the waypoint names.
[Off]: Turns off the names.
4. Press the MENU/ESC key to close the main menu.
2.1.14 How to show or hide the weather data
You can display the direction and the speed of the wind analyzed from type 16/36
message when the weather data is received from a beacon station (see page 7-2).
Note: This menu requires internal or external DGPS/DGLONASS beacon receiver.
1. Press the MENU/ESC key to open the main menu.
2. Select [1 Display] then [0 Data
Overlay].
3. Select [1 Weather (Type16/36)],
then [1 On] or [2 Off].
[On]: Displays the weather data
(type 16/36 message) on the plotter
display.
[Off]: Turns off the weather data (type 16/36 message) on the plotter display.
Note: On the highway display, the weather data is displayed regardless of on/off.
4. Press the MENU/ESC key to close the main menu.
Track
T
T
T
T
akap
4m/s
Plotter display
akap
4m/s
Highway display
The arrow points in wind direction
and its length changes according
to wind speed.
