2. INTERPRETING THE DISPLAYS
2-6
Description of ship's speed display indications (con't from previous page)
Fore-aft speed* Speed in the fore-aft direction. The speed setting range is 0.0 to 40.0 (kn). Fore
speed is denoted with a yellow "" above the speed readout and aft speed with
a yellow "" below the speed readout.
Port-starboard
speed*
Speed in the port-starboard direction. The speed setting range is 0.0 to 40.0
(kn). Port speed is denoted with a red "" to the left of the speed readout and
starboard speed with a green "" to the right of the speed readout.
Drift angle* The angle measured in degrees between ship's heading and the actual move-
ment. When drift angle is to port, a red "" appears and when it is to starboard
a green "" appears. In the NAV mode, drift in water tracking speed is shown.
Trip Shows trip distance. The distance is referenced to fore or fore/aft depending on
the setting of LOG PULSE OUT in the I/O menu.
Item Description
Own ship vector* The own ship vector shows port-starboard speed on the x-axis and
fore-aft speed on the y-axis. The "synthesized speed vector" (green)
appears when SCALE SYNC in the DISP2 menu is set to ON.
Fore-aft speed history graph This graph shows fore-aft speed history over time, which is useful in
trawling. HISTORY in the DISP2 menu sets the maximum range for
the graph, and you can shift the range with HISTORY SHIFT in the
DISP2 menu. The latest 60 minutes of fore-aft speed is shown, scroll-
ing from right to left across the screen.
Port-starboard history graph This graph shows port-starboard speed history over time, which is
useful in trawling. DRIFT HISTORY in the DISP2 menu sets the max-
imum range for the graph. The latest 60 minutes of fore-aft speed is
shown, scrolling from right to left across the screen.
*: Speed used for calculation depends on setting of SHIP SPD MODE in the DISP1 menu.
GT/WT: Speed is calculated according to tracking mode, ground speed for ground tracking mode
and water speed for water tracking mode.
WT: Speed is calculated using water tracking speed regardless of speed tracking mode in
use.
