2. INTERPRETING THE DISPLAYS
2-9
Ship’s track
Ship’s track is drawn with a white solid line. Ship’s track starts extending from the
screen center and when own ship position reaches the edge of the screen it is brought
back to the screen center. The ship’s track history is saved in three laps display width.
You can hide this track, see "SHIP TRACK" on page 3-9.
Tide vector
The five vectors for each layer are shown in each color. The interval to display the vec-
tors depends on the setting for the tide display interval described below. You can hide
each vector, see "TIDE VECTOR (LAYER 1 to LAYER 5)" on page 3-6.
North mark
The north mark points upward on the course plot display.
Scale
You may choose the scale with [SCALE] in the [DISP 3] sub menu.
DIV
Shows range per scale division.
Tide display interval
You may change the interval to display the tide vectors in the plot display. For exam-
ple, if the this value is 2.0, the tide vectors are shown each two scales. Accordingly
you can see the actual distance between the tide vectors by the value of [DIV], see
"INTERVAL" on page 3-9.
Position
Position which is input from the plotter is shown in latitude and longitude.
