5. MENU OPERATIONS
5-10
Note: Previous backup data will be overwritten.
4. Press the MENU key to backup the system settings. The system releases a series
of beeps to indicate that the data is saved, then the [System] menu appears.
5. Press the MENU key to close the menu.
How to restore your settings
1. Referring to section 5.5, open the [System] menu.
2. Press or to select [Load Backup Data] (full system settings) or [Load Preset
Data] (partial settings), then press . A confirmation window appears. The exam-
ple below shows the full system settings confirmation window. Note that the title
at the top of the window changes depending on your selection.
3. Press or to select [No] or [Load Internal Data], as appropriate.
• [No]: No backup data is loaded, settings remain unchanged.
• [Load Internal Data]: System settings are loaded from the Transceiver Unit’s in-
ternal memory and replace the current settings.
4. Press the MENU key to load the system settings. The system releases a series of
beeps to indicate that the data is saved, then the [System] menu appears.
5. Press the MENU key to close the menu.
5.11 How to Adjust the Transmission Frequency
If the system is receiving interference from a video sounder to other sonar on your
ship, adjust the frequency to reduce interference.
1. Referring to section 5.5, open the [System] menu.
2. Press or to select [TX Frequency Offset], then press . The [TX FREQ. Ad-
just] window appears.
3. Press to increase the transmission frequency, or press to decrease the trans-
mission frequency.
4. Press the MENU key twice to close the menu.
Load Backup Data
Are You Sure?
Note:
Current settings will be overwritten.
: Change
Menu: Apply
No
Load Internal Data
TX FREQ. Adjust
1 8 0. 0 k H z
FREQ. Shift :
(
1 7 1 ~ 1 8 9k
Hz
)
: Change Menu: Apply
Frequency range and default
settings are dependent on
the transducer. This figure
shows the TX FREQ. Adjust
options for the 150 kHz
transducer.
