5. MENU OPERATIONS
5-5
5.6 FUNC Key Menu
The system has three function keys which can be customized to suit your needs. Each
key can be assigned either as a preset key, or as a short-cut key.
Preset keys store the display mode, sector, train angle, scan range, tilt angle, scan
speed and gain. This allows you to preset for specific operations.
Short-cut keys provide quick access to preset functions. The short-cut key options are
not changeable.
5.6.1 How to setup the function keys
To setup a function key, do the following:
1. Referring to section 5.5, access the [System] menu.
2. Press or to select [System Settings], then press . The [System Settings 1]
menu appears.
3. Press to show the [System Setting 2] menu.
4. Press to select [FUNC Key1], [FUNC Key2] or [FUNC Key3], as required.
5. Press or to select [Preset Key] or [Short-Cut Key], as required.
6. Press the MENU key twice to close the menu.
5.6.2 Short-cut keys
You can select the function for each shortcut key as follows:
1. Referring to section 5.6.1, access the [FUNC Key] menu.
2. Press or to select the appropriate key.
3. Press or to select the required short-cut.The table below shows the options
available for each key.
4. Press the MENU key to close the menu.
Menu item Settings Description
[Key1] [Preset Key] Enable calling up the Preset key setting you have set.
[Key2] • [VERT Search]
• [Delete Mark]
• Enables the Vertical Search function.
• Deletes all event marks.
[Key3] • [VERT Search]
• [Delete Mark]
• Enables the Vertical Search function.
• Deletes all event marks.
Function keysFunction keys
