1. OPERATION
1-12
3. Click [Target Information].
4. Customize the data referring to the following table.
Available target data
The following data is available for the target information:
No. Name Description
1 [Main] box Data displayed in the main target information frame.
2 [Append] box Data displayed in the appended target information
frame.
3 [Hide] box The data registered in the [Hide] box is not shown in
either the main or appended target information
frames.
4 Frame change button Moves the data selected with the cursor to other set-
ting box.
5 Order change button Changes the order of the data selected with the cur-
sor.
Item Description
[NAME] Vessel name. For targets whose vessel name data is not available,
“<No Name>” appears.
[ID] • TT target: When the data source can be specified, radar ID and tar-
get ID are shown.
• AIS target: MMSI is shown.
[SIZE] Vessel size of the AIS target. For the TT target and AIS target whose
vessel size data is not available, “---- m --- m” appears.
[DEST] Destination (max. 20 characters). For the target whose destination
data is not available, “<No Destination>” appears.
[STATUS] Navigational status for the AIS target. For targets whose navigational
data is not available, “<No Navigational Status>” appears.
[TYPE] Vessel type for the AIS target. For TT/AIS targets whose vessel type
data is not available, “<No Type>” appears.
[RNG] Distance to the target.
[HDG] Target’s heading direction.
[COG] Target’s course over ground.
[CPA] Target’s CPA.
[TCPA] Target’s TCPA.
[BCR] Target’s bow cross range.
[BCT] Target’s bow cross time.
[SOG] Target’s speed over the ground.
1
2
2
3
3
4
4
5
5
