EN
9
Step 3
Insert the cooktop centered into the cutout opening.
Make sure the front edge of the counter top is parallel to the
cooktop. Make final check that all required clearances are met.
Step 4
Four clamp brackets are provided with your unit.
After cooktop has been installed into the countertop, install the
brackets on the burner box as shown in figure.
Install the clamp brackets on the front and back of the burner box
bottom (if the cabinet construction does not provide clearance for
installing brackets at the burner box front back install the clamp
brackets on the lateral position of burner box).
step A place the clamping screws into brackets
step B attach brackets by using the attachment screws on the
selected location of burner box, tighten screws just enough to hold
brackets in place.
step C position brackets so that they are with the clamp screw in
contact with the counter top bottom
step D tighten attachment screws securely.
step E check that the front edge of the cooktop is parallel to the
front edge of the countertop tighten the screw clamping against the
countertop.
DO NOT OVER TIGHTEN
