13
ACCESSORIES INCLUDED & INSTALLATION INSTRUCTIONS
Installation Instructions
In the Cool Mode the appliance must be
placed close to a window or opening so that
the warm exhaust air can be ducted outside.
First position the unit on a flat surface, and
make sure it is within the vicinity of a single
circuit outlet power source. Make sure there’s
a minimum of 19.7" clearance in the
front/back of the unit, and a minimum of
19.7" clearance in the left/right sides of the
unit.
EXHAUSTING HOT AIR
19.7"
19.7"
Accessories Included
PARTS: PARTS NAME:
QUANTITY:
Connector
Main Panel
1 pc
1 pc
Extender Panel 1 pc
1 pc
Clamp Plate & Clamp Plate Foam 1 set
Interface Panel 1 pc
Wedge & Velcro
Sealing Strip
Window Foam
Drain hose
1 set
7 pcs
1 pc
Telescopic Panel 1 pc
1 pc
Screws
4 pcs (3/4 screws)
2 pcs (1/2 screws)
Drain hose and connector
(for heat pump model)
1 set(78.7”(2m))
Panel connector
Note: Clamp plate foam and one of the 1/2” screw are provided as spare
