5. BEFORE USING THE OVEN
WARNING!
Refer to Safety chapters.
5.1 Oven Vent Location
The oven air vents are located in the rear side of the cooktop. When
the oven is on, warm air is released through the vent. This venting is
necessary for proper air circulation in the oven and good baking
results.
Steam or moisture may appear near the oven vent. This is normal.
IMPORTANT
Do not block oven vent or cover the openings with aluminium foil or
any other material.
WARNING!
Protective Liners — Do not use aluminum foil (or any other
material) or liners to line the oven bottom, walls, racks or any other
part of the range. Doing so will alter the heat distribution, produce
poor baking results, and possibly cause permanent damage to the
oven interior. Improper installation of these liners may result in risk
of electric shock or fire. During self clean, temperatures in the oven
will be hot enough to melt foil.
CAUTION!
Always use pot holders or oven mitts when using the oven. When
cooking, the oven interior, oven exterior, oven racks, and cooktop
will become very hot which can cause burns.
Remove all oven racks before starting a self clean cycle. If oven
racks are left inside the oven during a cleaning cycle, the slide
ability of the oven racks may be damaged and all of the oven racks
will lose their shiny finish.
To prevent possible damage to the oven, do not attempt to close
the oven door until all the oven racks are fully positioned back
inside the oven cavity.
5.2 Types of Oven Rack
Flat Oven Rack
Flat oven racks may be used for most cooking needs and may be
placed in most oven rack positions.
IMPORTANT
Before using the accessories, remove and clean them according to
the instructions in the chapter: "Care and Cleaning".
5.3 Removing and Arranging Oven Racks
IMPORTANT
Always arrange the oven racks when the oven is cool.
To remove oven racks
1. Pull the rack straight forward until it reaches the stop position.
2. Slightly lift up front of the oven rack and slide it out.
To replace oven racks
1. Place oven rack on the rack guides on both sides of oven walls.
2. Lift the front of the oven rack slightly upward and slide it back into
place.
Ensure that oven rack is level before using it.
5.4 Using Menu Options to Customize Your Cooking
Experience
When you first install your appliance, the screen will prompt you to set
your preferences. You can always change them later using the menu
.
1. Touch the Menu Options bars and scroll to find the desired option.
2. Select option and set your preference.
3. Save and go back or Save & Close.
You can press the X to close without saving changes.
5.5 Oven Light
To activate the oven light, open the Menu Options and slide to
choose the setting for Oven Light .
5.6 Clock
When the appliance is first plugged in or when the power supply to the
appliance has been interrupted, the display will show 12:00. It is
recommended to always set the clock for the correct time of day before
using the appliance.
To set the clock:
1. Touch Menu Options bars and scroll to Clock.
Clock options
Turn off the clock display when the oven is off
Change from 12- hour to 24-hour time
Set the clock
2. Touch Set Clock and set time using graph.
3. Set AM or PM.
4. Save & Close.
5.7 Energy Saving Mode
The oven control has a factory preset built-in 12- hour Energy Saving
feature that will turn off the oven if it is left on for more than 12 hours.
You can program the appliance to override this function and allow
continuous baking for more than 12 hours.
1. Scroll to Energy Saving Mode and touch.
2. Follow the information to override the Energy Saving Mode if
necessary.
3. Save & Close.
5.8 General Settings
You can change some settings of your appliance.
To do this:
1. Scroll to General Settings and touch.
2. Choose one of the settings you would like to change.
Setting Description
Temperature Unit To change from °F (default) to °C.
Volume Level To choose oven control to operate with loud, quiet or
no tones.
Screen Brightness Level To choose display brightness level from: high, medium
and low.
Language Available languages: English, French Canadian, Span‐
ish.
Cooking Tips To choose if the Cooking Tips are displayed on the
screen or not.
10 ENGLISH
