5. With steel clamp and screw, secure
water supply line to rear panel of the
appliance.
6. Coil excess water supply line (copper
tubing only), about 2.5 turns, behind
refrigerator as shown and arrange
coils so they do not vibrate or wear
against any other surface. Do not kink
tubing.
7. Turn on water supply at shutoff valve
and tighten any connections that leak.
8. Reconnect refrigerator to electrical
power source.
9. Turn the ice maker on.
servi
c
e
mo
d
e
Copper tubing installation
A
B
E
F
D
H
C
I
G
Braided flexible stainless steel tubing
installation
A
B
J
F
H
K
G
A. Plastic water tubing to ice maker fill
tube
B. Steel clamp
C. Brass compression nut
D. Ferrule (sleeve)
E. Copper water line
F. Water valve bracket
G. Valve inlet
H. Water valve
I. Copper water line from household
water supply*
J. Braided flexible stainless steel water
line
K. 6 ft (1.8 m) braided flexible stainless
steel water line from household water
supply*
*Include enough tubing in the loop to allow
moving the refrigerator out for cleaning.
7. ICE MAKER
7.1 Automatic ice maker
NOTE
Automatic ice makers are optional
accessories that you may install in
most models at any time. Visit
Frigidaire.com for information about
ice maker kit 117000
.
If your appliance has an automatic ice
maker, it will produce minimal ice during
the first 24 hours of operation. Air in new
plumbing lines may cause the ice maker to
cycle 2 or 3 times before making a full tray
of ice. With no usage, it will take
approximately 1 to 2 days to fill the ice
container.
New plumbing connections may cause the
first production of ice cubes to be
discolored or have an odd flavor. Discard
the ice produced during the first 24 hours.
NOTE
The ice maker is shipped in the ON
position. To ensure proper function for
your ice maker, hook up the water
supply immediately or turn the ice
maker OFF. If the ice maker is on and
the water supply is not connected, the
water valve will make a loud
chattering noise.
16 ENGLISH
