B
A
A. To household water supply
B. To unit water valve
3. Open the locking clips and grab the
water line coming from the refrigerator.
Remove the plastic cap from the water
inlet fitting and discard the cap.
4. If using (recommended) stainless steel
braided tubing - the nut and the ferrule
are already assembled on the tubing.
Slide the compression nut onto the
water inlet fitting and finger tighten.
5. Using two 1/2" wrenches, one to hold
the household water line nut (A) and
the other to hold the water inlet fitting
nut (B), tighten a half turn with the
wrench (A). Do not over tighten.
B
A
6. Replace the connected tubes into the
clips and lock the clips back in place to
keep the tubing in the right position.
7. Turn on water supply at shutoff valve
and tighten any connections that leak.
8. Reconnect refrigerator to electrical
power source.
9. Turn the ice maker on.
10. Purge air from the Ice and Water
Dispenser System by operating the
water dispenser for 3 - 4 minutes. This
requires dispensing several glasses of
water.
7. CONTROLS AND SETTINGS: EXTERNAL WATER
DISPENSER MODEL - TYPE 1
Switching On/Off
To switch on the appliance, connect the power cord to the outlet.
To switch off the appliance, disconnect the power cord from the outlet.
Control display
Cold Drink
Timer
Reset
Water Filte r
Ice
Maker
Reset
Air F ilter s
Chill
Boost
Freeze
Boost
1
2
3
4 11
12
13
14
1520 161819 17
5 6 8 9 107
ENGLISH 15
