MOUNT T
HE MICROWAVE
OVEN
2
Rotate front of oven
up against cabinet
bottom.
Insert a self-aligning screw through top
center cabinet hole. Temporarily secure the
oven
by turning the screw at least two full
turns after the threads have engaged. (It
will be completely tightened later.) Be sure
to keep power cord tight. Be careful not to
pinch the cord, especially when mounting
flush to bottom of cabinet.
N
OTE: When mounting
the microwave oven,
thread power cord
through hole in bottom of
top cabinet. Keep it tight
throughout Steps 1–3. Do
not pinch cord or lift
oven by pulling cord.
Lift
microwave,
tilt it forward, and
hook slots at back
bottom edge onto
four lower tabs of
mounting plate.
1
CHECK FOR PROPER
DAMPER OPERATION
Exhaust Adaptor
Blower Plate
Damper
Back of
Microwave
• Make sure tape securing damper is removed
and damper pivots easily before mounting
microwave.
• You w
ill need to make adjustments to assure
proper alignment with your house exhaust
duct after the microwave is installed.
5
Secure blower unit to microwa
ve with
the screw removed in Step 1. Make sure
t
h
e screw is tight.
Replace blower plate with the screw
removed in Step 1. Make sure the screw
is tight.
Back of
Microwave
6
7
Back of
Microwave
Guide
Adaptor
Attach the exhaust adaptor to the top
of the blower plate by sliding it into the
gu
ides
of the
blower plate.
Locking Tab
Push in securely until it is in the
loc
king
tabs.
Take care to assure that
the damper hinge
is
installed so that
the
damper swings freely.
.
.
I
nstallation Instructions
C
3.
C
4
C5
ADAPTING MICROWA
VE
BLOWER FOR OUTSIDE
TOP EXHAUST
(cont.)
EN-22
FOR E
AS
IER INSTALLATION AND PERSONAL
SAFETY, WE RECOMMEND THAT TWO
PEOPLE INSTAL
L THIS MICROWAVE OVEN.
IMPORTANT: Do not grip or use the handle or
hea
t shield during installation. Do not remove
the cardboard spacers between the heat
shield and door.
NOTE: If your cabinet is metal, use the nylon
grommet around the power cord hole to
prevent cutting
of the cord.
NOTE: We recommend using filler blocks if the
cabinet front hangs below the cabinet bottom
shelf.
IMPORTANT: If filler blocks are
not used, case damage may occur from
overtightening screws.
