NOTE: Before tightening toggle bolts and wood
screw
, make sure the bottom of the mounting
plate touch the bottom of the cabinet when
pushe
d flush against the wall and that the plate is
properly centered under the cabinet.
CAUTION: Be careful to avoid pinching fingers
between the back of the mounting plate and the
wall.
Tighten all bolts. Pull the plate away from the
wall to h
elp tighten the bolts.
4
ATTACH THE MOUNTING
PLATE TO THE WALL
B3.
• Read the instructions on the TOP
CABINET TEMPLATE.
• Tape it underneath the top cabinet.
• Drill the holes, following the instructions
on the TOP CABINET TEMPLATE.
CAUT
ION: Wear safety goggles when
drilling holes in the cabinet bottom.
Wall
Mounting
Plate
Toggle
Bolt
Spacing for Toggles
More Than Wall
Thickness
Togg
le Wings
To use toggle bolts:
Bolt End
I
nstallation Instructions
Attach the plate to the wall using toggle
bolts. At least one wood screw must be
used to attach the plate to a wall stud.
Remove the toggle wings from the bolts.
I
nsert the bolts into the mounting plate
through the holes designated to go into
drywall and reattach the toggle wings to
3
⁄4″
(19 mm) onto each bolt.
1
2
Place the mounting plate against the wall
and
insert the toggle wings into the holes
in the wall to mount the plate.
3
2
1
Remove and save screw that holds
blower motor to microwave.
ADAPTING MICROWA
VE
BLOWER FOR OUTSIDE
BACK EXHAUST
B5.
End B
En
d A
Back of
Microwave
Blower Motor
Blower
Motor Screw
Carefu
lly pull out the blower unit. The
wires will extend far enough to allow
you to adjust the blower unit.
Before: Fan
Blade Openings
Facing Forward
USE TOP CABINET TEMPLATE
FOR PREPARATION OF TOP
CABINET
B4.
You need to drill holes for the top support
screws and a hole large enough for the power
cord to fit through.
Back of
Microwave
Roll the blower unit 90°
Back of
Microwave
3
Before Rotation After Rotation
EN-17
