14
DOOR HANDLE INSTALLATION (METAL)
To attach the metal refrigerator handle:
1. With the door open, place the rounded
part of the handle onto the shoulder
screw on the face of the door and align
the 2 holes in top of handle with the 2
holes in top of the door. Do not tighten
the set screw yet.
2. Install the 2 screws into the top of
the handle.
3. Tighten the set screw on the rounded
part of the handle until the handle
is flush with the door; then tighten
another ½ turn.
To attach the metal freezer handle:
1. With the door open, place the rounded
part of the handle onto the shoulder
screw on the face of the door and
align the 2 holes in bottom of handle
with the 2 holes in bottom of door. Do
not tighten the set screw yet.
2. Install the 2 screws into the bottom of
the handle.
3. Tighten the set screw on the rounded
part of the handle until the handle
is flush with the door; then tighten
another ½ turn.
Screw
Handle
Set
Screw
Shoulder
Screw
Shoulder
Screw
Handle
Set Screw
Screw
For Professional models:
With the door open, place the handle over the shoulder screw tighten the set screws.
