SPECIFICATIONS

Cool w/ Heat Pump + Electric Heat (208/230V) (7k and 9k BTU)

Figure 203

Model PZH07K2SC PZH07K3SC PZH09K3SC

Power supply V-Ph-Hz 230/208V /60Hz 230/208V /60Hz 230/208V/60Hz

Power supply type Single-phase power supply Single-phase power supply Single-phase power supply

Cooling

Capacity Btu/h 7000/6800 7000/6800 9200/9000

Input W 590/570 590/570 805/790

EER Btu/h.W 11.9/11.9 11.9/11.9 11.4/11.4

Amps A 2.6/2.8 2.6/2.8 3.6/3.9

Heating

Capacity Btu/h 6000/5800 6000/5800 8000/7800

Input W 500/485 500/485 690/670

COP W/W 3.5/3.5 3.5/3.5 3.4/3.4

Amps A 2.3/2.4 2.3/2.4 3.1/3.3

Electric heating

Capacity (230/208V) Btu/h 8500/6900 12000/10000 12000/10000

Power input (230/208V) W 2550/2090 3650/2990 3650/2990

Rated current (230/208V) A 11.1/10 15.9/14.3 15.9/14.3

Sensible Heat Ratio

89% 89% 85.9%

Moisture Removal pints/hr 0.69 0.69 1.37/1.69

MCA A 15 20 20

MOP

A

15 20 20

Power factor 0.93/0.95 0.93/0.95 0.97/0.98

Max. input consumption W 850 850 1050

Max. current A 3.9 3.9 5.3

Compressor

Compressor 39X142GA$54LY 39X142GA$54LY 39X192GD&5JLA

Type Rotary Rotary Rotary

Brand RECHI RECHI RECHI

Capacity Btu/h 6050 ± 5 % 6050 ± 5 % 8470± 5 %

Input W 470 ± 5 % 470 ± 5 % 650 ± 5 %

Rated current(RLA) A 2.4 2.4 3.4

Locked rotor Amp(LRA) A 13.4±10% 13.4±10% 17.5±10%

Thermal protector °F 275±13(Built-in) 275±13(Built-in) 275±13(Built-in)

Capacitor uF 15 15 25

Refrigerant oil ml FW68DA 160ml FW68DA 160ml FW68DA 180ml

Indoor fan

motor

Model YDK-25-4-1 YDK-25-4-1 YDK-25-4-1

Brand Li Feng Li Feng Li Feng

Insulation class B B B

Input W 60 60 60

Output W 25 25 25

Rated current A 0.3 0.3 0.3

Capacitor uF 2 2 2

Speed(hi/mi/lo) r/min 900/850 900/850 1000/850

Indoor air ﬂow (Hi/Lo) cfm 350/330 350/330 390/330

Indoor Fan Noise Level(230V) dBA 49/44 49/44 49/44

Indoor Fan Noise Level(208V) dBA 49/44 49/44 49/44

Indoor Fan Noise Level((230V))cooling

mode

dBA

53/51 53/51 52/50

Indoor Fan Noise Level(208V)cooling mode dBA 52/50 52/50 52/50
