14

PB

Model PZE09R3SC PZE12R3SC

Outdoor fan

motor

Model YDK-45-4P2 YDK-45-4P2

Brand KB KB

Insulation class A A

Safe class IPX4 IPX4

Input W 90 90

Output W 45 45

Rated current A 0.3 0.3

Capacitor uF 2 2

Speed r/min 1600 1680

Outdoor fan

material ABS+G15 ABS+G15

Type axial ﬂow axial ﬂow

Diameter in. 13 3/4 13 3/4

Height in. 4 1/8 4 1/8

Outdoor air

ﬂow cfm 706 706

Outdoor sound level(sound pressure level )(Heating mode) dB(A)±2 66 66

Unit

Dimension(W*H*D) in. 42*21*16 42*21*16

Packing (W*H*D) in. 45*25*19 45*25*19

Net/Gross weight lbs 94/105 94/105

Charged refrigerant type oz 19 22.2

Throttle type Capillary Capillary

Design pressure PSI 493/232 493/232

Power Cord plug (20A) (20A)

Controller push-button control push-button control

Operation temp °F 60-90 60-90

Ambient temp cooling °F 53-114 53-114

Ambient temp heating °F 35-75 35-75

SPECIFICATIONS

Cool w/ Electric Heat (265V)

Figure 202
