SPECIFICATIONS

Cool w/ Heat Pump + Electric Heat (208/230V) (12k and 15k BTU)

Friedrich Model PZH12K3SC PZH12K5SC PZH15K5SC PZH15K3SC

Power supply V-Ph-Hz 230/208V /60Hz 230/208V /60Hz 230/208V /60Hz 230/208V /60Hz

Power supply type

Single-phase power

supply

Single-phase power

supply

Single-phase power

supply

Single-phase power

supply

Cooling

Capacity Btu/h 12000/11800 12000/11800 14500/14300 14500/14300

Input W 1130/1110 1130/1110 1450/1430 1450/1430

EER Btu/h.W 10.6/10.6 10.6/10.6 10.0/10.0 10.0/10.0

Amps A 5.0/5.4 5.0/5.4 6.4/7.0 6.4/7.0

Heating

Capacity Btu/h 10400/10200 10400/10200 13600/13200 13600/13200

Input W 895/880 895/880 1245/1210 1245/1210

COP W/W 3.4/3.4 3.4/3.4 3.2/3.2 3.2/3.2

Amps A 4.0/4.4 4.0/4.4 5.5/6.0 5.5/6.0

Electric heating

Capacity (230/208V) Btu/h 12000/10000 17000/13900 17000/13900 12000/10000

Power input

(230/208V)

W

3650/2990

5050/4135 5050/4135

3650/2990

Rated current

(230/208V)

A

15.9/14.3

21.9/19.8 21.9/19.8

15.9/14.3

Sensible Heat Ratio

78.3% 78.3%

68.6% 68.6%

Moisture Removal pints/hr 2.32/2.56 2.32/2.56 4.29/4.44 4.29/4.44

MCA A 20 30 30 20

MOP

A

20 30 30 20

Power factor 0.99/0.98 0.99/0.98 0.99/0.98 0.99/0.98

Max. input consumption W 1450 1450 2050 2050

Max. current A 8.0 8.0 11 11

Compressor

Compressor 44X2623KTFJMZ 44X2623KTFJMZ 44X362KK&FJMD 44X362KK&FJMD

Type Rotary Rotary Rotary Rotary

Brand RECHI RECHI RECHI RECHI

Capacity Btu/h 11565±5% 11565±5% 16150±5% 16150±5%

Input W 855 ±5% 855 ±5% 1225 ±5% 1225 ±5%

Rated current(RLA) A 4.5 4.5 6.4 6.4

Locked rotor Amp(LRA) A 23.9±10% 23.9±10% 34.7±10% 34.7±10%

Thermal protector °F 311±9(Built-in) 311±9(Built-in) 293±9(Built-in) 293±9(Built-in)

Capacitor uF 30 30 30 30

Refrigerant oil ml FW68DA 240ml FW68DA 240ml FW68DA 320ml FW68DA 320ml

Indoor fan

motor

Model YDK-25-4-1 YDK-25-4-1 YDK-25-4-1 YDK-25-4-1

Brand Li Feng Li Feng Li Feng Li Feng

Insulation class B B B B

Input W 70 70 70 70

Output W 25 25 25 25

Rated current A 0.4 0.4 0.4 0.4

Capacitor uF 2 2 2 2

Speed(hi/mi/lo) r/min 1150/900 1150/900 1150/900 1150/900

Indoor air ﬂow (Hi/Lo) cfm 450/340 450/340 450/340 450/340

Indoor Fan Noise Level(230V) dBA 52/45 52/45 53/46 53/46

Indoor Fan Noise Level(208V) dBA 52/45 52/45 52/46 52/46
