Figure 203

SPECIFICATIONS

Cool w/ Heat Pump + Electric Heat (208/230V) (7k and 9k BTU)

Model PZH07K2SC PZH07K3SC PZH09K3SC

Indoor Fan Noise Level(230V)heating mode dBA 53/51 53/51 52/50

Indoor Fan Noise Level(208V)heating mode dBA 52/51 52/51 51/50

Indoor sound level (sound pressure level)

(Fan mode) dB(A)±2 49/44 49/44 49/44

Outdoor fan

motor

Model YDK-55-4P2-4 YDK-55-4P2-4 YDK-55-4P2-4

Brand chigo/KB chigo/KB chigo/KB

Insulation class A A A

Safe class IPX4 IPX4 IPX4

Input W 104 104 104

Output W 55 55 55

Rated current A 0.5 0.5 0.5

Capacitor uF 3 3 3

Speed r/min 1600 1600 1600

Outdoor fan

material ABS+G15 ABS+G15 ABS+G15

Type Axial ﬂow Axial ﬂow Axial ﬂow

Diameter in. 13 3/4 13 3/4 13 3/4

Height in. 4 1/8 4 1/8 4 1/8

Outdoor air

ﬂow cfm 706 706 706

Outdoor sound level(sound pressure level)

(Heating mode) dB(A)±2 67 67 67

Unit

Dimension(W*H*D) in 42*21*16 42*21*16 42*21*16

Packing (W*H*D) in 45*25*19 45*25*19 45*25*19

Net/Gross weight lbs 92.6/104 92.6/104 95/106

Charged refrigerant type oz 17.6 17.6 18.7

Throttle type capillary capillary capillary

Design pressure PSI 493/232 493/232 493/232

Power Cord plug （LCDI-15A（（LCDI-20A（（LCDI-20A（

Controller

Control panel;

(Optional: Remote control

/24V wired control)

Control panel;

(Optional: Remote control

/24V wired control)

Control panel; (Optional:

Remote control /24V wired

control)

Operation temp °F 60-90 60-90 60-90

Ambient temp cooling °F 53-114 53-114 53-114

Ambient temp hating °F 35-75 35-75 35-75
