50 50

FRONT FRAME WITH

MESH FILTER

ALIGN HOLES WITH

PROTRUSION

ROUTINE MAINTENANCE

Premium Carbon Filter Removal / Installation Instructions -Kuhl

Figure 419

1. Remove the lter per Standard Filter Removal Installation Refer to Figure 415 and 416.

2. Hold the lter at the top and slide the grip out as shown on Figure 417.

3. If you already have a carbon lter installed remove the dirty lter by laying the lter down and swinging open the front frame as shown in Figure 419.

NOTE: Make sure the frame with the mesh is facing toward you.

4. Place the new carbon lter on the top of the back lter frame. The carbon lter has been cut to the correct dimension and should t within the frame

as shown in Figure 420.

NOTE:

The carbon lter is not a reusable lter, and needs to be replaced every three months for optimum efciency.

5. Slide the lter handle back on to hold the frames together and slide the assembly into the unit as per the instructions

on the door.

NOTE: The lter handle slides into the frame in only one direction. If the tab in the frame stops the handle from sliding in, slide the handle from the other

direction. DO NOT FORCE THE HANDLE INTO THE FRAME.

Figure 420
