12
Replace the lower hinge part to the11.
left side and fixing it with the special flange
self-tapping screws. Replace the adjustable
bottom feet parts
to another side and fixing it.
12. Transfer the lower door to the
property position, adjust the lower hinge part,
make the hinge axis into the lower hole of the
lower door, then tight the bolts.
Upturn the middle hinge part the13.
direction 180 degree, transfer it and adjust its
position, make the middle hinge axis into
the upper hole of the lower door, tight the
bolts.
middle hinge part
selftapping screws
14. Transfer the upper door to the
appropriate position. Secure the door’s level,
make the middle hinge axis into the lower
hole of the upper door.
15. Transfer the upper hinge part and
make the upper hinge axis into the upper
hole of the upper door, and adjust the
position of the upper door
(please support the upper door with your
hand when doing it), fixing the upper hinge
part with the special flange self-tapping
screws.
upper hinge part
16. Install the screw hole cover on the
top right corner of the refrigerator. Install the
upper hinge cover (which is in the plastic bag)
on the left corner. Put the other upper hinge
cover into the plastic bag.
upper hinge cover (left)
17. Open the upper door and install the
door shelves, then close it.
screw hole
cover
Warning!
When changing the side at which the door
opens, the appliance must not be connected
to the mains. Remove plug from the mains
beforehand.
