11
6.. Place the upper door on a smoo
surface with its panel upwards. Loose
screw ②
and part ①, then Install them to
the left side and tighten
①
Stop block
①
②
Self-tapping screw
②
7.. Unscrew the two special flange sel
tapping screws which are used for fixing the
middle hinge part, then remove the middle
hinge part that hold the lower door in place.
NOTE: When removing the door, watch for
washer(s) between the lower hinge and the
bottom of the lower door that may stick to the
door. Don’t lose it.
. Place the lower door on a smoo8.
surface with its panel upwards. Loose screw
② and part ①, then Install them to the left
side and tighten securely.
. Change screw hole covers on midd9.
cover plate from left to right (as shown in
figure below).
Stop bloc
①
②
Self-tapping scre
①
②
screw hole covers
screw hole covers
10.0. Lay the refrigerator on soft f
packaging or similar material. Remove both
adjustable bottom feet parts, and remove the
front feet board and the lower hinge part by
unscrewing the special flange self-tapping
screws.
