depends on the parameters indicated in
the selection.
Select the digit with and press “8” in
the power bar.
Select the front left digit and select the
correct setting.
See the following table for the specifica-
tions:
Value on the
power bar
KW Notes
0 7.4
Standard initial setting
1 4.5
2 3.5
3 2.8
Once the correct value has been
entered, confirm by touching and hold-
ing .
10. HOB FUNCTIONS
Child lock
This function prevents accidental use of the appliance. This cannot be used during a cooking operation
To enable: remove all cookware from the appliance, turn the appliance off. If there is no pan on the hob,
press and hold for 3 seconds one of the 5 digits (not visible) next to the point on the left side. Release
and slowly swipe along the power bar from 0 to BOOST. All the digits that indicate .
The operations described must be completed within 10 seconds.
To disable: turn the appliance on and then press and hold any of the 5 digits for 3 seconds. Release and
slowly swipe along the power bar from BOOST to 0. The 5 digit displays will lit up indicating and 0 power
level.
The operations described must be completed within 10 seconds.
Lock
It is possible to lock the hob functions during use, e.g. to clean the hob. The function is enabled even if
the hob is switched off and on again.
If the electricity supply is cut, the function is disabled.
To enable: press and hold for 1 second.
To disable: press .
Boost function
Every cooking area can be set to an additional power level for a maximum of 5 minutes.
To enable: select one of the 4 cooking areas and select “P” on the power bar. The corresponding digit in-
dicates .
To disable: select one of the other possible values on the power bar.
Cooking zone
timer
The timer allows a specific cooking area to be switched off when the set time expires.
The cooking areas can be programmed individually because each one has its own timer.
To enable: With the cooking area in operation, press to access the timer management controls for that
zone.
The 3 digits indicate “0 0 0”. Press “+” or “-” to set the timer countdown.
Hours - Tenths - Minutes
To confirm the set time, do not touch anything for 10 seconds.
When the countdown has finished, the digits are reset and an audible signal is emitted. The function can
be interrupted by pressing any key.
If the timer is enabled for more than one cooking area, the 3 digits will always show whichever timer is
about to finish first.
To deactivate: with the cooking area in operation, press to access the timer management controls for
that zone.
Set the three digits to “0 0 0” using “+” or “-” or press the On/Off key.
25
