If the ignition is not successful within 15 seconds, turn the knob to OFF and wait for 60 seconds
before attempting the ignition. This product is equipped with rapid ignition device, when the knob is
released, the igniter will continue to keep the ignition state for 1-3 seconds, do not touch the ignition
needle immediately to avoid electric shock.
■ Step 5：Installation procedure
WARNING
Check the ignition
Check the flame quality
• This appliance is equipped with an electronic ignition device. Simply press the knob
downward and turn it counterclockwise to HI. Then, you will hear clicking sounds, which
indicates proper operation of the ignition system.
• Once air is purged from the supply line, the burner should light within 3-5 seconds, and
the clicking sounds will stop.
• After the burner lights, rotate the knob to your desired position.
• Try each burner in succession until all burners have been checked.
• Determine the quality of flames visually. Normal burner flames should look like following
2 pictures.
• Long, bright yellow flames are not normal. Normal flames may show signs of an orange
tint when well heated or signs of flickering orange due to particles in the gas or air.
(A) Soft blue flames -
Normal for natural gas
(B) Yellow tips on outer cones -
Normal for ULPG gas
-17- -18-
Installation of the pan support:
1.Make sure the short side of pan support is placed in front and the long side is placed in rear.
2.The pan support should be lowered perpendicularly to the panel.
3.No frictions back and forth.
Installation procedure Installation procedure
IMPORTANT
In the process of installation and operation,
the pan support should be placed carefully
in case of scratches on liquid tray and glass
surface. Make sure the shorter side of each
pan support is placed in front and the
longer side is placed in rear. The manufac-
turer waives all responsibility for scratches
or damages caused by improper personal
operation.
long side
short side
■ Install the grates
1.Left/Right Grate(same) 2.Center Grate 1.Left Grate 2.Center/Right Grate(same)
GLG90305&GLG90305-Y
1 2 1
GLG90505
1
2
2
Rapid grate
1.Rapid grate only for rapid burner and
semi-rapid burner
2.The rapid grate has been designed for
supporting cookware with a base
diameter smaller than 200mm.
3.Ensure cooktop is cool before slotting
the rapid grate onto the burner grate as
shown.Ensure all notches rest securely
on the burner grate before use
GLG60305&GLG60305-Y
1.Left Grate
2.Right Grate
1 2
The cooktop grates are designed to fit in
specific positions on the cooktop. For
maximum stability, these grates should
only be used in their proper positions.
