-15- -16-
Installation procedure Installation procedure
1. Identify Wok/Rapid/Semi-rapid/Auxiliary burner head and burner cap by size.
Other burner assembly:
2. Hold the burner head, then find the gap “C” and ignition needle “D”, make it on the same side.
3. Place the burner head with the gap “C” next to the ignition needle “D” and make sure the burner
head is firmly seated.
C
D
4. Place the lined part of burner cap to fit in the lined part of the burner head. Shake the burner
cap gently to check if it is firmly seated.
5. Check if the burner head/burner cap is firmly seated. If the burner head/cap is not level or is
unstable, you must take it off, and reinsert it again.
4. Next, place the inner burner cap on the burner head and make sure it is firmly set by gently
sliding it from side to side.
5. Check if the burner head/burner cap is firmly seated. If the burner head/cap is not level or is
unstable, you must take it off, and reinsert it again.
3. Place the lined part of outer burner cap to fit in the lined part of the burner head. Shake the
outer burner cap gently to check if it is firmly seated (you will be able to rotate the outer burner
cap, but it should be firmly seated in the burner head.)
2. Place the burner head onto the cooktop surface so that “hole A” gets inserted into “pin B” on
the cooktop. Make sure “Pin B” is firmly seated into “hole A” on the Burner Head. If not,
remove the burner head and try it again. Please refer to the pictures below for this step.
B
