Attach the microwave oven to the top cabinet.
Cabinet Front
Cabinet Bottom Shelf
Tighten the outer two screws to the top of the
microwave oven. (While tightening screws, hold
the microwave oven in place against the wall
and the top cabinet.)
Filler Block
Microwave Oven Top
Equivalent to
Depth
of Cabinet
Recess
Insert 2 self-aligning screws
through outer top cabinet holes.
Turn two full turns on each screw.
ADJUST THE EXHAUST
ADAPTOR
Open the top cabinet and adjust the exhaust adapter
to connect to the house duct.
For Front-to-Back or Side-
to-Side Adjustment, Slide
the Exhaust Adapter as
Needed
Back of
Blower Plate
Damper
Microwave
Self-Aligning Screw
5
A5.
CONNECTING DUCTWORK
1
2
A7.
House Duct
MOUNT THE MICROWAVE
(cont.)
A6.
Install grease filters. See the Use & Care
Guide packed with the microwave.
8
Extend the house duct down to connect to the
exhaust adapter.
Seal exhaust duct joints using furnace duct tape
for high temperature applications
4
7
EN-16
