UTOPIA CINEMA
User manual
For the purposes of improvement or to take into account any legal or regulatory changes, FOCAL-JMLab reserves the right to modify the technical
specifications of its products without prior notice. Where required, any images shown are for illustrative purposes only,
and may differ slightly from the products sold.
To facilitate the Focal-JMlab warranty,
it is now possible to register your product online at: www.focal.com/garantie
Thank you for purchasing a Focal product. Welcome to our world. Our values are innovation, tradition, excellence and plea-
sure; our one and only aim is to bring you a sound that is rich, pure and true. To get the most out of your product, we recom-
mend that you read the instructions in this booklet, then store it in a safe place to refer to in the future.
Package contents
CINEMA LCR
• Loudspeaker
• Grille
• 4 brackets
• 4 spacers
• 24 screws
• Cut-out template
• Logo
Running-in period
The speaker drivers used in the Integration UTOPIA CINEMA loudspeakers are complex mechanical components which need
a break-in period to operate at their best and to become acclimatised to the temperature and humidity of your environment.
This running-in period varies depending on the conditions in question and may take several weeks. To reduce this time, we
recommend operating your loudspeakers for about twenty consecutive hours at a moderate power level. Once the louds-
peakers' characteristics have stabilised completely, you will be able to enjoy your Integration UTOPIA CINEMA loudspeakers’
performance to the full.
Spacers
Spacers should be fitted to the underside of the loudspeaker (depending on whether it is vertical or horizontal) – CINEMA
LCR, see fig.1 – CINEMA SUB, see fig.11. These prevent vibrations once the loudspeaker has been installed and, in the case of
stacked loudspeakers, prevent the UTOPIA CINEMA range loudspeakers from sticking to each other.
Connection
UTOPIA CINEMA loudspeakers can be powered via Speakon connectors or a push spring terminal (CINEMA LCR, see fig.2 –
CINEMA SUB, see fig.12). You will only be able to install your loudspeakers once you have wired them up. Make sure you leave
enough cable length to be able to easily connect your product. If you are using the push spring terminal, we recommend using
the cable with a marker to ensure the polarity of the speaker drivers is respected (+/-). Choose cables of the appropriate
quality and cross-section for the length and power.
Choosing an amplifier
It is not an excess of amplifier power that can damage your loudspeaker and drivers, but rather a lack of power. In fact, if the
volume is too high, the amplifier saturates and generates parasite signals that may destroy the tweeter. The dynamic capa-
city and definition of Integration UTOPIA CINEMA loudspeakers are high enough to reveal the strengths and weaknesses of
whatever amplifier is connected to them.
Fastenings
When installing the four brackets, follow the different mounting points depending on the orientation of the UTOPIA CINEMA
loudspeaker (CINEMA LCR, see fig.3 – CINEMA SUB, see fig.13).
The installation configuration of the UTOPIA CINEMA loudspeaker may vary depending on the mounting points selected on
the bracket. It is up to the installer to make this decision. The loudspeaker can therefore be installed flush with the partition
wall or with an internal or external offset (CINEMA LCR, see fig.4 – 4.1 – CINEMA SUB, see fig.14 – 14.1).
F = Front Mounting / Loudspeaker mounted flush with the partition wall
B = Back Mounting / Loudspeaker projecting
CINEMA SUB
• Loudspeaker
• Grille
• 4 brackets
• 4 spacers
• 24 screws
• Cut-out template
• Logo
