4
ii905/ii915
Users Manual
PDQ Mode™. PDQ Mode is a capture mode that detects and
locates potential partial discharges. The PDQ Mode indicates a
possible type of Partial Discharge (External, Internal, Tracking, or
Other), Pulse count indication/minute, and Phase-resolved Partial
Discharge Plot (PRPD plot).
Partial Discharge (PD). PD is a localized dielectric breakdown that
does not completely bridge the electrical insulation between two
conductors under high voltage.
PD types are classied into three main types:
• External discharge, or corona discharge, is the ionization of
a uid, gas, or air surrounding a conductor that is electrically
charged at high voltage.
• Internal discharge occurs in voids or cavities within solid or
liquid dielectrics.
• Surface discharge tracks across the surface of dierent
insulation materials.
MecQ™. MecQ is a capture mode that detects and locates potential
anomalies in mechanical components as an early identication of
possible mechanical deterioration that requires further inspection.
Power On/O
To turn on the Imager, push and hold
O
>2 s.
To turn o the Imager, push
O
. Tap OK to continue.
Power and Charging Indication
• The power button ashes to show the Imager is starting.
• The power button identies the state of the battery: red is low
power, amber is charging, and green is fully charged.
Battery
XW
Warning
To prevent personal injury and for safe operation of the Product:
• Do not put battery cells and battery packs near heat or re.
• Do not put in sunlight.
• Do not disassemble or crush battery cells and battery packs.
• Remove batteries to prevent battery leakage and damage
to the Product if it is not used for an extended period.
• Connect the battery charger to the mains power outlet
before the Product.
• Use only Fluke approved power adapters to charge the battery.
• Keep cells and battery packs clean and dry. Clean dirty
connectors with a dry, clean cloth.
W
Caution
To prevent damage to the battery:
• Do not expose battery to heat sources or high-temperature
environments such as an unattended vehicle in the sun.
• Do not store the battery on the charger for more than
24 hours as reduced battery life may result.
• Charge the battery for a two-hour minimum at six-month
intervals for maximum battery life. Without use, the battery
will self-discharge in approximately six months.
• Always operate in the specied temperature range.
• Do not incinerate the Product and/or battery.
