ii905/ii915
Users Manual
4. Push Capture button or Save in the menu.
The Imager saves the still photo of the scene with overlapping
sound image and values in .PNG or .JPG format. You can add
notes, photo notes, or tags to the image. See Memory for more
information.
Note
For best results:
• Move the Imager around the leak to nd the highest LeakQ
value. This will best reect the actual leak size.
• Obstacles within the circle can inuence the calculated
distance and LeakQ value.
• High background noise will inuence the calculated
distance and LeakQ value.
PDQ Mode™ (ii915)
PDQ Mode™ captures data from a Partial Discharge (PD) that
enables further analysis such as type of discharge and severity. The
PD must be inside the circle on the display.
When a PD is detected, the PD Count value on the display gives an
indication of the pulses generated by that partial discharge.
The value is based on the pulses of the acoustic interference
generated by the PD:
• Values for estimated DISTANCE show on the display.
or
• NO TARGET FOUND shows on the display when no PD is
detected inside the circle.
If the Imager cannot automatically determine the distance,
this pop-up message shows on the display:
UNABLE TO ESTIMATE DISTANCE
If the Imager is unable to determine the distance, or you want
to override the estimated distance, you can input the distance
manually. See LeakQ™ Mode.
Note
See LeakQ Mode for instructions on capture. (not releated
to PD Count)
The Imager saves the still photo of the scene with overlapping
sound image and values in .PNG or .JPG format. You can add
notes, photo notes, or tags to the image. See Memory for more
information.
MecQ™ Mode (ii915)
MecQ™ mode detects and locates potential anomalies in
mechanical components as an early identication of possible
mechanical deterioration that requires further inspection.
See LeakQ™ Mode for instructions on capture and save.
