July 2024
24
View Recorded Video
Latitude, Horizon, Meridian Control Center User Guide
Icon
Label/Name
Description
Create Bookmark
Create a Bookmark at the current Timeline Cursor position
3.4.7.2 Time Ruler
Icon
Name
Description
ScrollBack/Forward
Click with the mouse to scroll the contents of the Timeline
window backwards or forwards
TimeRuler
Shows the scale of the current Timeline window.
Note: You can adjust (compress/expand) the scale. Position
the mouse on the Time ruler (it changes to the
symbol)Click and Drag - left (expands), right
(compresses)
3.4.7.3 Tracks
The default Timeline display only shows the Bookmark and Clip Timeline tracks.
Figure 20 - Default Timeline Showing Bookmark and Clip Timeline Tracks
Click on the Expand tracks icon in the Timeline Toolbar to show/hide additional details
about the replayed clip.
Figure 21 - Detailed Timeline Showing Additional Information Tracks
Table 2 - Timeline Track Icons
Track
Description
Bookmarks
All bookmarks for any of the displayed clips are shown.
All Recordings
The blue bar shows times during with there are recordings for this
camera.
Note: If ‘show motion’ is ON, then the dark areas in the bar show times
during which the System registered that there is movement on the
camera.
Manual
Indicates time during which recordings are made as a result of the user
manually clicking ‘Record’ (manual recording).
Schedule
Time during which recordings are made as a result of a Schedule.
Events
Times during which Events are associated with this camera.
Alarms
Times during which alarms are associated with this camera.
