July 2024
11
Common Tasks
Latitude, Horizon, Meridian Control Center User Guide
3.3.2 Remove a Video from a Tile
You can remove a displayed video from Control Center viewing tiles.
Do one of the following:
·
In the Control Center, click the video to be removed, and drag it anywhere out of the Viewing
pane.
Figure 7 - Click and Drag a Video Out of the Viewing Pane
-or-
·
In the Control Center, right-click the video and select the Remove option.
The selected video is removed.
3.3.3 Use the Layout Pane to Change the Pattern of the Viewing Tiles
This section discusses how to use the layout pane to change the viewing tiles pattern.
The layout pane provides the user with a comprehensive set of pattern options for how to
arrange viewing tiles in a layout. These patterns range from the simple four-tile default layout,
through multiple matrix layouts that show up to 32 simple rectangular tiles, various mixes of large
and small tiles that allow some areas to be shown in large tiles with others on the edges for
monitoring, to specialized patterns that cater for wide-angle views such as are used by ‘stitched’
scenes.
Click on any of the patterns in the layout pane to change the viewing pane arrangement to the
selected pattern. Tiles are re-arranged, with each tile from the old pattern being displayed in the
tile with the corresponding tile number in the new pattern.
3.3.3.1 Spot Monitor Option
The Spot monitor option enables the user to designate a specific tile to be used whenever a
scene is double-clicked, regardless of the current Active Tile.
Spot Monitor is useful if you want to always view for the results of a double-click in the same
location.
The following procedure describes how to enable the Spot monitor option.
