61November 2022
Cameras Screens
Horizon/Meridian Admin Center Help File
Editing a Motion Detection Zone
Any Motion Detection Zones that are defined for this camera will be indicated by
numbered blocks in the Preview Window.
Click on the zone in the list to select it. The corresponding zone will be highlighted with a
red outline in the Preview window.
The sides of the zone can be changed by hovering the mouse over the edge to get the
double-arrow symbol, and the edge can then be dragged larger or smaller.
Hovering the mouse inside the zone will give a four-headed arrow, and then whole zone
can then be dragged to a different position.
Adding a Motion Detection Zone
Clicking on the Add Zone button adds a new entry to the list of Motion Detection Zones,
and indicates the area covered with a corresponding number and a shaded block
outlined in red showing the extents of the zone.
You can edit the name given to the zone by clicking on the name, typing the new
description, and clicking Apply.
Deleting a Motion Detection Zone
Click on the zone to be deleted to select it, and then click on the Delete button. You will
be asked to confirm that you want to delete the zone.
Note. There must always be at least one Motion Detection zone defined.
Changing Motion Detection Settings
Sensitivity, Threshold - Default settings are assigned by the system when the camera
is discovered. These should generally not be altered.
Pre - and Post- Recording (Seconds) - For cameras that are set to record based on
Motion Detection, the system records continuously, and when a motion detection event
occurs, then a clip is created including pre-event and post-event recording as defined by
these parameters.
Create Bookmark upon motion on - Check this box if bookmarks are required for all
motion events.
Saving your Settings
Select the required settings, and then click Apply.
6.4.1.6
Analytics Settings
The Analytics Tab allows the user to set up Intrusion Zones, virtual Tripwires and Masking
Areas to be monitored by the Analytics capability of the camera.
For information about cameras that support Basic Analytics (Ariel Gen III, CF-6308, etc) see
Basic Analytics
