16
RD SP 12/18/230
Storage
temperature
-40~70℃
Charging
temperature
4~40℃
Charger
12V
CA 12/18, CA 12,
CA 10.8/18.0, CA 10.8
18V
CA 12/18, CA 18.0-LD,
CA 10.8/18.0
*When USB and USB-C ports use at the same
time, the maximum output cannot exceed
2.1A.
* IP64 is true when the battery compartment
cover and AC power inlet cover are closed.
Overview (see figure A)
The numbering of the product features refers
to the illustration of the machine on the
graphics page.
1. Handle
2. Antenna
3. Spring-loaded latch
4. Latches
5. Bottle opener
6. AC power inlet cover
7. Cable wrap
8. EQ button
9. Mode button
10. Display
11. Tune/seek down button
12. Tune/seek up button
13. Bluetooth-pairing button
14. Clock button
15. On/off/volume knob
16. Mute button
17. Play/pause button
18. Battery compartment
19. Aux connector
20. USB power port
21. USB-C power port
22. Battery compartment cover
23. AC power cord
24. Aux cable
Assembly
WARNING!
Remove the battery before carrying out any
work on the radio.
Before switching on the radio
Unpack the stack pack radio and check that
there are no missing or damaged parts.
Inserting/replacing the battery
■
Press down the battery compartment
latch (B-1) first and open the battery
compartment cover (see figure B1).
■
Press the charged battery into the radio
until it clicks into place (see figure B2).
■
To remove, press the release button and
pull out the battery (see figure B3).
■
The power of the battery is displayed
simultaneously on the display (10).
CAUTION!
When the device is not in use, protect the
battery contacts. Loose metal parts may short
circuit the contacts; explosion and fire hazard!
U
sing the AC power cord
(see figure C)
■
Open the AC power inlet cover (6).
■
Insert the AC power cord (23) into the
socket (C-1).
■
Plug the AC power cord plug (23) into a
standard power outlet.
■
The radio can charge the battery when the
AC power cord (23) is connected.
■
USB devices such as cell phones, MP3
players, etc. connected to USB power ports
(20 &21) can be charged when the AC
power cord (23) is connected.
■
The AC power cord plug (23) should be
disconnected from the power outlet when
not in use.
A
ttaching/ detaching storage
box
(not included)
To attach the radio to the box:
■
Align the steps (D-1) at the bottom of the
radio with the spring-loaded latches (D-2)
on both ends of the box.
■
Press down the radio against the box,
the spring-loaded latch (D-2) will secure
automatically (see figure D).
■
The storage box can be placed either
under the radio or on top of it.
To detach the radio from the box:
