5 Intended use
Mobile dust extractor suitable for
– Extracting dust up to 0,1 mg/m³ according
to dust class 'M', including wood and paint
dust,
– Extracting water,
– Increased loads during commercial use,
according to IEC/EN 60335-2-69.
The user is liable for improper or non-in
tended use.
6 Commissioning
WARNING
Unauthorised voltage or frequency!
Risk of accidents
► Observe the specifications on the ma
chine's name plate.
► Observe country-specific regulations.
6.1 Initial commissioning
► Open the locking clips[2-2] and remove the
top section of the machine[2-1].
► Remove the accessories from the dirt
trap[2-3] and the packaging.
► Place a filter bag or disposal bag in the dirt
trap (see sections10.1 and10.2).
► Replace the top section[2-1] and close the
locking clips[2-2].
► Attach the cord holder to the reverse of the
mobile dust extractor (see figure[3]).
► Connect the suction hose to the machine
and note the hose diameter adjustment (see
section8.1).
6.2 Connecting a mobile dust extractor
WARNING
Risk of injury from tools starting up unex
pectedly
► Before switching on, ensure that the con
nected tool is switched off.
WARNING
Risk of injury from electric current
► Insert the mains plug into an earthed sock
et.
► Do not reach into the electrical outlet mod
ule on the mobile dust extractor.
While the mobile dust extractor is connec
ted to the mains socket, an electric cur
rent is running through the electrical out
let module on the mobile dust extractor at
all times.
Connecting the mobile dust extractor to a
mains socket
The mobile dust extractor is switched off.
► Connect the power cable to a mains socket.
The electrical outlet module[1-3] is live.
Switching the mobile dust extractor to standby
mode
► Press the on/off switch[1-14].
The electrical outlet module[1-3] is live.
The green LED[1-11] indicates standby
mode.
Starting the mobile dust extractor automati
cally
The mobile dust extractor is in standby mode.
► To start the mobile dust extractor automati
cally: Switch on the connected tool.
Starting the mobile dust extractor manually
The mobile dust extractor is in standby mode.
► Press the MAN button[1-13].
Pull the mains plug from the socket
when you are not using the mobile dust
extractor and before performing any
cleaning and maintenance work.
7 Connecting a device
WARNING
Risk of injury from the mobile dust extractor
starting up unexpectedly
► Before performing any work with the mo
bile dust extractor, check which remote
control and which power tool are connec
ted to the mobile dust extractor.
► The remote control must only be attached
to the suction hose.
► A battery-powered power tool must always
be connected to the mobile dust extractor
via the suction hose. After finishing work,
the connection to the mobile dust extractor
must be disconnected.
English
22
