9 Working

9.1 Handling

Hose holder: After finishing work, you can feed

the suction hose through the opening[8-2] and

place it in the hose holder.

SYS-Dock Systainer storage area: A Systainer

can be fastened to the storage area with the

four slides or the T-Loc lock[8-1].

9.2 AUTOCLEAN – cleaning the main filter

(variants with AUTOCLEAN only)

Only in conjunction with a disposable

bag (to comply with dust class "L"). Not

for use during wet extraction.

Switching automatic cleaning on and off

► In standby mode, press the AC button[1-9]

to switch AUTOCLEAN on or off.

The AC function can be configured using

the FestoolApp*.

Manual cleaning

► Press the AC button[1-9] while extracting.

Full manual cleaning

► While extracting, cover the end of the nozzle

or suction hose with your hand or CT-VS

closing slide for three seconds.

► Press and hold the AC button[1-9] for at

least three seconds.

Do not clean the main filter too often within a

short period of time.

Within 1minute maximum:

1x full manual dedusting

3x manual dedusting

*Not available in all countries.

9.3 Special features of the CTL 36 E AC-

LHS

To use the mobile dust extractor in combination

with the PLANEX:

► Use kink-resistant suction hose D 36 mm x

3.5 m-AS.

► Use a special suction sleeve for connecting

the

PLANEX.

► Use closing slide CT-VS between the intake

opening[1-1] and suction hose.

► Attach the tool holder.

► Always use with a disposal bag!

Bypass function

In tasks that require a low extraction setting

(e.g. on soft surfaces).

► Activate bypass function on special extrac

tion sleeve[1A].

9.4 Extracting dry materials

 

CAUTION

Hazardous dust

Damage to the respiratory passage

► Always use a filter or disposal bag.

When extracting dust that exceeds the

limit value, only extract from one dust

source (power or compressed-air tool).

Observe the following when extracting dust

generated by operating electric power tools:

If the exhaust air is discharged back into

the room, the air renewal rate L within the

room must be sufficient. The volume of air dis

charged back into the room must not exceed

50% of the fresh air volume flow (room volume

x air renewal rate L

). In addition, observe

the national regulations.

Observe the following: A moist main filter

clogs more quickly when extracting dry mate

rials. Therefore, dry the main filter before ex

tracting dust or replace the damp filter with a

dry one.

9.5 Extracting wet materials/liquids

Remove the filter/disposal bag.

Use a special wet filter (NF-CT).

The dust extraction stops automatically when

the maximum fill level is reached.

The bottom LED[1-10] flashes red.

It must be ensured that the machine (main fil

ter, suction hose, container, etc.) is sufficiently

dried after extracting wet materials.



CAUTION

Hazardous dust

Damage to the respiratory passage

► After extracting wet materials, remove the

wet filter and replace it with the main filter

for dry materials.



CAUTION

Escaping foam and liquids

► Switch off and empty the machine immedi

ately.

9.6 After finishing work

► Variants with AUTOCLEAN only: Clean the

main filter automatically or manually (see

section9.2)

► Switch off the mobile dust extractor and

pull out the mains plug.

English
