Festo — EPCE-TB — 2023-11d

Commissioning

WARNING

Danger of burns from hot housing surfaces.

Metallic housing parts can reach high temperatures during operation.

Contact with metal housing parts can cause burn injuries.

• Do not touch metallic housing parts.

•

After the power supply is switched off, let the device cool down to room temperature.

Update device data only with IO-Link.

• Updating firmware

• Updating parameter set

• Data backup (Data Storage)

èInstruction manual for "Integrated drive EMCS" èwww.festo.com/sp

9.1

Commissioning: DIO operation (digital I/Os)

Preparation:

Check mounting of the drive system.

Check wiring of the power supplies and the "DI/DO" digital inputs and outputs at the [Power] and

[Logic] connections.

Procedure:

Switch on load voltage.

Apply the logic supply [Logic Pin 1] at least 50 ms after the load supply 24 V DC [Power Pin 1]. For

example, ensure the switch-on delay by interposing relay contacts.

Disconnect the logic supply [Logic Pin 1] after a shutdown, after an interruption or before restoring

the load supply 24 V DC [Power Pin 1].

If the logic voltage is switched on before the load voltage, there is a risk of an irreversible device

defect in rare cases.

Wait for initialisation until C/Q LED is yellow (L7s).

4. Select the reference end position"Ref" from the HMI interface in the "Reference" menu and

start the homing with end position detection (only required if the reference end position"Ref"

is different from the factory setting or if the useful range has been changed). The drive system is

referenced after a successful homing.

Referencing sets the start press position "Pos

Start Press

" equal to the calculated useful range.

5. Parameterisation of operating modes via HMI interface:

Basic parameters for point-to-point operation with and without press function or manual opera-

tion (demo)

– "Speed Out" speed

– "Speed In" speed

additional parameters for point-to-point operation with press function

–

"Force"

– Start Press "Pos

Start Press

" position (reference point end position"Ref")
