Technical data

ELGS-BS-KF -32 -45 -60

Certificates, declaration of

conformity for EMCS-ST

www.festo.com/sp

Mounting position Any

Ambient temperature [°C] 0…+50

Storage temperature [°C] –20…+60

Degree of protection IP40

Max. payload in horizontal

mounting position

[kg] 2 10 20

Max. payload in vertical

mounting position

[kg] 2 5 13

Max. speed with axial kit

[m/s] 0.18 0.25 0.25

Max. speed with parallel kit

[m/s] 0.18 0.235 0.215

Velocity "SpeedPress/

SpeedRef"

[m/s] 0.01

Max. feed force

3)4)

[N] 40 100 200

Max. force on external stops

during homing

[N] 60 151 288

Max. acceleration/decelera-

tion with axial kit

[m/s

] 5

Max. acceleration/decelera-

tion with parallel kit

[m/s

] 3

Duty cycle [%] 100 (+30…+50°C:–2% per Kelvin)

Distance between stop and

end position

[mm] 1

Repetition accuracy [mm] ±0.015 ±0.015 ±0.01

Nominal voltage [VDC] 24

Logic current consumption

(logic, pin1)

[A] DIO operation: 0.1…0.3

IO-Link operation: 0.1…0.15

Load current consumption

(power, pin1)

[A] 3 3 5.3
