07
MAIN DISPLAY
Main display
The status bar is located at the bottom:
The synchronization source and the current sample frequency are displayed in the
middle. This can be selected in the CLOCK view.
Higher Samplerates
The ADAT interface was originally only specied for sampling rates up to 48kHz. To
support higher sampling rates without changing the type of transmission, sampling
rates up to 96kHz combines 2 channels, and respectively. 4 channels at 192kHz.
To the left are the two ADAT, as well as the BNC input sockets shown. For a quick
overview, the color of the socket indicates the state of the input signal:
Grey
Yellow
Green
No signal found
Signal found but cannot be synchronized to selected clock source
Signal found and used
In the upper area the levels of the 8
inputs and 8 outputs are shown. As
already described, you should
absolutely avoid clipping, and
therefore for example control the
level only up to -6dB. Any clipping
that may occur is indicated by a
ashing bar at the top and can be
deleted by briey pressing the
POWER button.
On the right side, activity of the MIDI and USB jack is displayed. Once USB is connected
to a computer and mounted, a chain icon appears to the right of the USB icon to show
the successful connection.
Since the Pulse8 AE has two ADAT input and two ADAT output jacks, even at 96kHz 8
channels per direction can still be transmitted via ADAT.
SMUX/1
SMUX/2
SMUX/4
32kHz, 44.1kHz, 48kHz
64kHz, 88.2kHz, 96kHz
128kHz, 176.4kHz, 192kHz
8 ADAT channels per jack
4 ADAT channels per jack
2 ADAT channels per jack
