06
BACK VIEW
WORDCLOCK IN/OUT9
The WORDCLOCK IN jack is used to receive and synchronize the clock from other
digital devices. Set the clock source to BNC in the CLOCK view. The current clock
is output to the WORDCLOCK OUT jack.
ANALOG IN/OUT10
On the right back there are 8-analog inputs in the upper row, as well as 8-analog
outputs at the bottom, which are designed balanced using 6.3mm TRS jacks. The
outputs have a maximum output level of 20dBu, while the inputs also process a
maximum of 20dBu input level.
Balanced connections
If possible, use only balanced cabling to ensure the best possible audio quality. If you
still want to make an unbalanced cabling, please follow this:
Unbalanced connection of analog outputs
Connect only the tip (TIP) of the jack as a signal line, and the ground return line
(SLEEVE) at the base of the jack, leaving the middle ring open (RING). The maximum
output signal in this case is 6dB lower, i.e. 14dBu.
Unbalanced connection of analog inputs
Also connect only the tip (TIP) for signal, and the ground return (SLEEVE). It is
recommended to connect the ring to ground to prevent interference on this line.
Please note that the maximum level is only 14dBu. In the Gains menu, you should raise
the corresponding gain by 6dB for a full signal.
Clipping
Please always set the gain of the inputs in such a way that digital clipping is prevent-
ed by keeping enough headroom to full level. In contrast to analog devices, the signal
is heavily distorted in the event of a clipping, which is why this situation must be
avoided at all costs.
Any clipping that may occur is displayed in the level indicator as a red ashing bar. To
delete this, briey press the POWER button. You can also deactivate the clipping
display function in the DAC or ADC view.
