18
PULSE16 I/Os – ADAT
ADAT® is a digital multichannel interface standard by Alesis®. It can
transfer eight channels of audio data at 48kHz via an optical plastics fibre.
The maximum length of an ADAT connection is limited to 10 meters.
The PULSE16 has four pairs of ADAT I/O ports. The ports with white doors
are the outputs, the black ones are the inputs.
Each ADAT interface can transfer eight channels at SMUX/1. When using
SMUX/2 the channel count reduces to 4. Since the PULSE16 is equipped
with four ADAT interface In/Out pairs, transfer of all analog 16 input and
16 output channels is still possible.
SMUX/4 (up to 192kHz) is only enabled when the MADI MX upgrade is
installed. In this case only two channels are transferred over a ADAT cable,
resulting in 8 input and 8 output channels in total, unsing the four interface
pairs.
* SMUX/4 is only available for Pulse16 MX or Pulse16 with MADI option installed
Frequency
ADAT channels in+output
32kHz, 44.1kHz, 48kHz (SMUX/1)
32+32
64kHz, 88.2kHz, 96kHz (SMUX/2)
16+16
128kHz, 176.4kHz, 192kHz (SMUX/4)
8+8*
