17
PULSE16 I/O’s – analog inputs and outputs
All analog inputs and output can be found on in balanced ¼” (6.3mm) TRS
jacks, and can be set independently to a level/sensivity between -8dBu and
+20dBu. All inputs and outputs are fully balanced.
The pinout of the TRS connections is:
Tip = hot, Ring = cold, Shield = ground.
When using balanced (TRS) cables, always make sure that all three contacts
are connected. When using TRS plugs with unbalanced (2wire) cables,
make sure that RING and SLEEVE are connected with each other.
The reference levels on the analog side mean a value of
0dBFS on the digital side, when set to an input sensitivity
of +4dBu and feeding the input with a signal level of
+4dBu (1.22Vrms).
