10
HEADPHONES SETUP
In this setup menu, you can set the amplification levels of
the two headphone outputs separately. These can be adjusted
to limit the maximum volume of an headphone output or
increased for higher impedance headphones.
In addition, the operating mode can be switched between
"unbalanced" (dual stereo) and „balanced".
The most common mode of operation for the two stereo outputs is probably "dual stereo", while "balanced" is intended for high-end headphones
with balanced cabling. In this case, the red output is used for the left driver of the headphones and the blue output for the right.
For the "balanced" mode, however, a special headphone cable is required from the headphone manufacturer. For safety reasons,
large volume jumps are prevented when selecting the gain levels. This is to protect your ears.
A32pro Series Manual: Main Menu
PRESET
In the preset menu, you can either load (LOAD), save (SAVE)
or rename (RENAME) one of eight presets.
Each preset can be assigned a name.
Naming and renaming of the preset names takes place
via an on-screen keyboard.
GAINS
The GAINS screen is used to adjust the sensitivity of the analog inputs. These are individually adjustable in 1dB steps from -8dBu to +20dBu.
The number below the fader indicates the maximum level that the converter can process. If the fader is set to a value of -7 on channel 1,
as in the picture above, the input can process a level of maximum -7dBu and would in this case output 0dBFS on the digital side. Values
exceeding this limit would lead to digital clipping. The meters are post-fader. In addition, you can see the level displays of the analog inputs so
that you can conveniently set the level correctly. You will find the dB scaling of the display on the right side of the screens. With a swipe gesture
at the points above and below the fader, you can select several channels and then adjust their value together with the encoder wheel.
The value of -8dBu corresponds approximately to the level of -10dBV for consumer devices such as CD players or a tape deck.
SETUP MENU
In the setup menu you have access to further adjustments
and functions, which, among other things, concern the
MADI and MIDI ports.
We will explain these in detail on the following pages.
SETUP MENU A32pro Dante
SETUP MENU A32pro
