- 9 -
2. There is a 2-3/4” hole in the lower corner of the compartment and a 2-3/4”hole plug in the compartment
back. Remove the 2-3/4” plug from the back hole and place it into the bottom hole.
3. Install and fasten the case onto the counter.
4. Drill a 1-1/2” hole through the counter back in the location of the 2-3/4” hole for power cord to be
dropped into cabinet compartment.
5. Reinstall the condenser cover and the (6) screws.
OPTON 3: An electrical cord connection hole is provided in the rear control panel next to the controls. A
1-1/2”dia hole through the counter is not required for this option. NOTE: Only a licensed electrician must
perform the electrical work required to move the cord to this optional position.
DANGER:
Electric shock hazard. Do not operate unit with panels removed.
1. Before or after the case has been installed onto the counter remove the (6) screws holding the condenser
cover and remove the condenser cover.
2. Remove the (4) screws holding the rear frame panel located under the door track. Loosen the (4) screws
holding the cutting board under each end of the cutting board. Tilt and lift the rear panel out from behind
the cutting board.
3. Remove the 7/8” hole plug located next to the controls in the control panel. Disconnect power cord
connections and move cord and cord strain relief from bottom hole in frame channel to the 7/8”hole in
the control panel. Reconnect power cord and plug bottom in frame channel with the 7/8” hole plug
removed from the control panel.
4. Reinstall the condenser cover and the rear frame panel and retighten the cutting board mounting screws.
Refrigeration Installation
Self Contained Models
The self-contained models are shipped from the factory with a completely operational 134A refrigeration
system and require no modifications or adjustments upon installation.
