• The cable can be looped if necessary, but make sure that is
not kinked or trapped when the hob is in position. Care
must be taken to avoid the cable being in contact with hot
parts of the appliance.
Replacing the mains supply cable
If the mains supply cable is damaged, then it must be
replaced by an appropriate replacement.
The mains supply cable should be replaced in accordance
with the following instructions:
Switch the appliance off at the control switch.
Open the terminal block on the underside of the hob.
Unscrew the terminal screws fixing the cable.
The “green-yellow” earth wire must be connected to
the terminal marked . It must be about 10 mm longer
than the live and neutral wires.
The “blue” neutral wire must be connected to the
terminal marked with letter (N) - the live wire(L1) must
be connected to the terminal marked with letter (L1)
(220-240V 1N～).
EN-15
N
L1
PE
220-240V
Connect to the mains power supply
220-240V 1N
~
Green-yellow
Blue
Brown
