26
EV200RL
Proportional band for 0–10V actuator Defines the range within which the controller operates
proportionally to the system error and determines the sensitivity of
the control system.
3-point actuator stroke time Characteristic opening/closing time of the 3-point actuator.
Mixing valve actuation factor Specifies the power-on time required by the servomotor to
increase the supply temperature by 1°C.
3-point actuator control differential Specifies the minimum difference between the calculated and
measured supply temperatures, beyond which the actuator starts to
operate.
Circulator start delay Indicates the delay time before closing relay no. 7 after recei-
ving the ON signal from the CH180WIFIRL master programmable
thermostat.
Circulator stop anticipation Indicates the delay time before opening relay no. 7 after recei-
ving the OFF signal from the CH180WIFIRL master programmable
thermostat.
5 - PAIRING THE CLIMATE MODULE TO THE NETWORK
To pair the EV200RL device with the CH180WIFIRL master programmable thermostat, proceed as follows:
1. Open the FAN BUILDER app and select the Pair with other devices function, then choose Pair with CH180WIFIRL
and enter the MAC address of the programmable thermostat;
2. Access the network configuration menu on the CH180WIFIRL by pressing the ZONE button for a few seconds;
23.0
1
36
DAY
[ MAN ]
MODE
DISP
PROG
ZONE OFF
ESC
RH%
1
ZONE
[ JOLLY ]
[ HOLIDAY ]
[ AUTO ]
[ OFF ]
OK COPY
3. Select the PAIR EV menu item and press OK to continue;
(The UNPAIR EV menu item allows you to unpair the EV200RL);
4. Use the PROG button to select the MAC address of the device to pair/unpair. The selected device’s MAC address will
be displayed in brackets: [ MAC ADDRESS ];
5. Write down the MAC address on the system sheet using the adhesive label provided on the product;
6. Confirm the pairing/unpairing by pressing OK. The CH180WIFIRL display will confirm the operation with (PAIR OK
/ UNPAIR OK).
