12
ENGLISH
ASPIRLIGHT HV
3 AERAULIC CONNECTIONS
3.1 AERAULIC ORIENTATIONS
The unit has 4 circular male connections of different Ø based on the size: for optimal function.
To correctly connect the air ducts, refer to the following diagram and stickers on the unit.
Table of unit aeraulic connection diameters
Code AP20050
Ø mm 160
It is advisable to install at least 500mm of hose to avoid transmitting vibration and bothersome noises caused by
the installation.
Depending on what system the unit will be installed in, it will be possible to duly direct the four aeraulic connections.
Below are the possible configurations:
THE UNITS ARE SHOWN SEEN FROM ABOVE AND MUST BE ORDERED WITH THE DESIRED CONFIGURATION
