19
INSTALLATION OF RANGE HOOD BODY
X = A - 5 1/16"
$
PP
; $PP
;
%[
5 1/16"
6
As shown, you have to
accommodate for the
height of the hood body
into your space overhead.
After determining bracket
height use the 8 Screws
from Component Page 8 to
assemble brackets.
$
PP
; $PP
;
%[
5
Min. 7 5/16"
Max. 12 13/16"
Option A
Steps 7a-7b-7c is an option for mounting and hood when access is available from above the ceiling/soft
(See page 20).
Option B
Steps 8a-8b-8c is an option for mounting the hood to the brackets when no access is available from above
and the soft is already completed (See page 22).
Choose the correct method of bracket installation
Assemble the Range Hood Mounting Brackets
Ref. Size Picture
G
1/8" x 3/8"
G
